Replacement Indoor Ultraviolet Electric Ballast / Transformers
All UV power supplies in this listing are for indoor / use under cover except for the UVG P/N 40051 ballast marked * which is a weather proof ballast. UV power controllers / ballast are sensitive to power surges so must me installed with a power surge protector direct before them.
We have the UV lamps to suit these ballasts listed separately which you can order by clicking here [except for the 2nd lamp in the drop down listing which which is a 4-pin 6w lamp and not a 2-pin one to suit the ballast listed here]
Depending on the variation selected in drop down menu for ballasts below.
|
Ballast Spec's
|
Item Specifics
|
Connection
|
|
Generic
06w 2-Pin x2
|
110v-240v for 6w UV lamp
with pins +/- 6mm apart
|
2-Pins On
Both Ends
|
|
Generic
14w 4-Pin x1
|
110v-240v for 14w UV lamp with
pins +/- 7mm x 8mm apart
|
4-Pins On
One End
|
|
Aquapro
10w to 40w
4-Pin x1
|
110v-240v 10w-40w UV lamps
4 pins +/- 7mm x 8mm apart
|
4-Pins On
One End
|
|
FSA Brand
10w to 40w
4-Pin x1
|
110v-240v 10w-40w UV lamps
4 pins +/- 7mm x 8mm apart
|
4-Pins On
One End
|
|
UV Guard
10w to 40w
4-Pin x1
|
UVG Indoor Power Supply
110v-240v 10w-40w UV lamps
4 pins +/- 7mm x 8mm apart
|
4-Pins On
One End
|
|
UV Guard
10w to 40w
4-Pin x1
|
UVG Outdoor Power Supply
110v-240v 10w-40w UV lamps
4 pins +/- 7mm x 8mm apart
|
4-Pins On
One End
|
LISTING IS FOR REPLACEMENT BALLAST ONLY AND DOES NOT INCLUDE A LAMP
The style and brand of the ballast may differ to the one displayed in the listing image but will perform at specified depending on your selection choice in the drop down selection menu.
Ultra-violet water sterilisation is one of the most effective methods of sterilising water, it uses no chemicals whatsoever and will leave no harmful residues in your water. UV is used as an effective alternative to chemical or thermal disinfection, as a result, it is used extensively in the water, food and medical industries as a proven technology.
Lamp specifications vary per the drop down selection menu which is detailed in the above table. For UV sterilisation to be effective and to attain the maximum flow rate of the unit, the water will need to be pre-filtered for sediment to at least 10 micron, optimally 5 micron or finer. Given sufficient pre-filtration UV is effective on all water sources, including rain, bore, town and river/lake water.
UV is effective at treating Bacteria, Viruses, Algae, Fungi and other Micro-Organisms up to 99.9999% efficiency on all water supplies and is effective at treating for Cryptosporidium, Giardia, Blastocysts and other cysts in water supplies.
It is recommended that this system is used in conjunction with a filtration system to maintain optimum efficiency, send us a message and we will be happy to recommend the most suitable unit for your application.
Full warranty does not cover UV bulb, as this is considered a consumable, there is a 30 day replacement guarantee on faulty bulbs and you will need to be able to verify that you have used a power surge protector with this system as the bulbs and ballast / transformer can be damaged by power surges
NB: Listing image 1 is of a Aquapro 20w to 40w ballast with 4-pins on one end
If you are not entirely satisfied with your purchase please contact us so that we can try to resolve your concerns
