Depending on the variation selected in drop down menu we'll supply as follows
|
UV Lamp Spec's |
Item Specifics |
Lamp Size |
|
06w | 3.8LPM | 2-Pin x2 |
6w | 3.8LPM UV Lamp | Two pins on both ends | Pins +/- 6mm apart |
L=220mm |
|
06w | 3.8LPM | 4-Pin x1 |
6w | 3.8LPM UV Lamp | Four pins on one end | +/- 7mm x 8mm apart |
L=220mm |
|
14w | 7.5LPM | 4-Pin x1 |
14w | 7.5LPM UV Lamp | Four pins on one end | +/- 7mm x 8mm apart |
L=295mm |
|
20w | 24LPM | 4-Pin x1 |
20w | 24LPM UV Lamp | Four pins on one end | +/- 7mm x 8mm apart |
L=443mm |
|
40w | 45LPM | 4-Pin x1 |
40w | 45LPM UV Lamp | Four pins on one end | +/- 7mm x 8mm apart |
L=845mm |
|
75w | 45LPM | 4-Pin x1 |
75w | 85LPM UV Lamp | Four pins on one end | +/- 7mm x 8mm apart |
L=845mm |
|
80w | 90LPM | 4-Pin x1 |
80w | 90LPM UV Lamp | Four pins on one end | +/- 7mm x 8mm apart |
L=845mm |
We can source any UV lamp size and wattage so feel free to message us here if you need to request a specific lamp not listed above
It's is generally okay if the replacement lamp you buy is a little shorter / narrower than your current lamp but it can't be longer / much wider or it may not fit into your quartz sleeve housing
Ultra-violet water sterilisation is one of the most effective methods of sterilising water, it uses no chemicals whatsoever and will leave no harmful residues in your water. UV is used as an effective alternative to chemical or thermal disinfection, as a result, it is used extensively in the water, food and medical industries as a proven technology.
Lamp specifications vary per the drop down selection menu which is detailed in the above table. For UV sterilisation to be effective and to attain the maximum flow rate of the unit, the water will need to be pre-filtered for sediment to at least 10 micron, optimally 5 micron or finer. Given sufficient pre-filtration UV is effective on all water sources, including rain, bore, town and river/lake water.
UV is effective at treating Bacteria, Viruses, Algae, Fungi and other Micro-Organisms up to 99.99% efficiency on all water supplies and is effective at treating for Cryptosporidium, Giardia, Blastocysts and other cysts in water supplies.
It is recommended that this system is used in conjunction with a filtration system to maintain optimum efficiency, send us a message and we will be happy to recommend the most suitable unit for your application.
Full warranty does not cover UV bulb, as this is considered a consumable, there is a 30 day replacement guarantee on faulty bulbs and you will need to be able to verify that you have used a power surge protector with this system as the bulbs and ballast / transformer can be damaged by power surges
Listing image 1 is of a 14w | 7.5LPM | 4-pin x1
Appearance of other variations may differ, images listed are only a reference
If you are not entirely satisfied with your purchase please contact us so that we can try to resolve your concerns
